Today we are going to learn about the recovery from a loss of one redo log member of a multiplexed group. Being the Oracle DBA we all know the importance of change in normal life as well as database life. A single change in the database makes a huge difference. We all are well known that all kind of data changes stores is known Redo logs. Multiplexing is a way to have a backup of redo log in Oracle.This scenario describes what happens when you lose one redo log member of a multiplexed group.It could happen for a simple media failure or because someone “needed” to free some space and saw that .log file!!!
It happens to me years ago and that was told to me by a system administrator.
when you have multiplexed your redo log group using several members as Oracle best practices suggest and your disks begin to experience problems your database will continue to function since it’s still able to write to one redo log member.
If your disk is completely out you can opt to some options whether or not you have a new disk!
With a new disk you can drop and create again the “lost” redo log member to the original location, otherwise you have to perform the same two steps (drop and create) choosing a different location.
Even if you have already lost your redo log member Oracle will arise the ORA-01609 error when you try to drop a member of a CURRENT group. Querying the status column of V$LOG view you can have several results and generally they are:
- CURRENT when that log file is “currently” written by the log writer process (ps -ef|grep lgwr)
- ACTIVE when that log file is required in case of a crash recovery (even if it’s already archived)
- INACTIVE when that log file is not required in case of a crash recovery.
So when you try to drop your “failed” redo log member and you receive the ORA-01609 error just force the database to switch to the next redo log group.
Let’s look it with an example. Here is my redo log configuration:
SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo02.log 2 CURRENT /home/oracle/app/oracle/oradata/orcl/redo02b.log 2 CURRENT /home/oracle/app/oracle/oradata/orcl/redo03.log 3 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 INACTIVE
As you can see I have three redo log groups formed by two multiplexed members and currently the redo log group number 2 is the CURRENT one. Now I simulate the lost of the redo log member named ‘redo02b.log‘.
[oracle@localhost ~]$ cd /home/oracle/app/oracle/oradata/orcl/ [oracle@localhost orcl]$ rm redo02b.log [oracle@localhost orcl]$ ll redo* -rw-rw---- 1 oracle oracle 52429312 Sep 5 12:58 redo01b.log -rw-rw---- 1 oracle oracle 52429312 Sep 5 12:58 redo01.log -rw-rw---- 1 oracle oracle 52429312 Sep 5 22:30 redo02.log -rw-rw---- 1 oracle oracle 52429312 Sep 5 12:55 redo03b.log -rw-rw---- 1 oracle oracle 52429312 Sep 5 12:55 redo03.log
As you cann see from the alert log appears the error
... Errors in file /home/oracle/app/oracle/diag/rdbms/orcl/orcl/trace/orcl_lgwr_8172.trc: ORA-00313: open failed for members of log group 2 of thread 1 ORA-00312: online log 2 thread 1: '/home/oracle/app/oracle/oradata/orcl/redo02b.log' ORA-27037: unable to obtain file status Linux Error: 2: No such file or directory ...
Now have a look at how the status column of V$LOGFILE view change (from NULL to INVALID) for the lost member
SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo02.log 2 CURRENT /home/oracle/app/oracle/oradata/orcl/redo02b.log 2 CURRENT INVALID /home/oracle/app/oracle/oradata/orcl/redo03.log 3 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 INACTIVE
I’ve lost a member of the CURRENT redo log group so I cannot drop it
SQL> alter database drop logfile member '/home/oracle/app/oracle/oradata/orcl/redo02b.log'; alter database drop logfile member '/home/oracle/app/oracle/oradata/orcl/redo02b.log' * ERROR at line 1: ORA-01609: log 2 is the current log for thread 1 - cannot drop members ORA-00312: online log 2 thread 1: '/home/oracle/app/oracle/oradata/orcl/redo02.log' ORA-00312: online log 2 thread 1: '/home/oracle/app/oracle/oradata/orcl/redo02b.log'
I have to force a redo log switch:
SQL> alter system switch logfile; System altered.
Now my redo log group state is as the following:
SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo02.log 2 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo02b.log 2 ACTIVE INVALID /home/oracle/app/oracle/oradata/orcl/redo03.log 3 CURRENT /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 CURRENT
And I can successfully drop and recreate my lost redo log member:
SQL> alter database drop logfile member '/home/oracle/app/oracle/oradata/orcl/redo02b.log'; Database altered.
SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo02.log 2 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo03.log 3 CURRENT /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 CURRENT
SQL> alter database add logfile member '/home/oracle/app/oracle/oradata/orcl/redo02b.log' to group 2; Database altered. SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# 2 order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo02.log 2 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo02b.log 2 ACTIVE INVALID /home/oracle/app/oracle/oradata/orcl/redo03.log 3 CURRENT /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 CURRENT
What’s happening ? My new redo log member is still INVALID ? What does it mean ?
If you look at the Oracle documentation INVALID could mean: inaccessible (as it was before) or just created (as I did few lines above).
Let’s look what it happens when I force logfiles to switch:
SQL> alter system switch logfile; System altered. SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# 2 order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 CURRENT /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 CURRENT /home/oracle/app/oracle/oradata/orcl/redo02.log 2 INACTIVE /home/oracle/app/oracle/oradata/orcl/redo02b.log 2 INACTIVE INVALID /home/oracle/app/oracle/oradata/orcl/redo03.log 3 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 ACTIVE 6 rows selected.
SQL> alter system switch logfile; System altered. SQL> select member, a.group#, a.status, b.status from v$log a, v$logfile b where a.group# = b.group# 2 order by a.group#, member; MEMBER GROUP# STATUS STATUS ------------------------------------------------------------ ---------- ---------------- ------- /home/oracle/app/oracle/oradata/orcl/redo01.log 1 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo01b.log 1 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo02.log 2 CURRENT /home/oracle/app/oracle/oradata/orcl/redo02b.log 2 CURRENT /home/oracle/app/oracle/oradata/orcl/redo03.log 3 ACTIVE /home/oracle/app/oracle/oradata/orcl/redo03b.log 3 ACTIVE 6 rows selected.
